Single Beam CO2 Sensor Low Power U91010004
产品型号 Product Number U91010004
检测气体 Target Gas CO2
检测范围 Measurement Range 400ppm～5000ppm (extended range to 10000ppm)
检测精度 Accuracy ± (50ppm + 5% reading)
响应时间 Response Time Depending on measurement period
工作条件 Operation Conditions -10～50℃; 0～95%RH (Non-condensing)
存储条件 Storage Conditions -40℃～70℃
供电电压 Power Supply DC 3.6V～5.5V，Ripple voltage < 50mV
平均工作电流 Average Current 0.02mA~10mA （Customized)
峰值电流 Peak Current < 120 mA
通讯接口 Communication Interface UART TTL (3.3V); I2C (upon request)
产品寿命 Life Expectancy 15 years
长期稳定性 Long-term Stability ≤2% F.S.
重量 Weight 5.7 grams
